Account for all components, hardware and fasteners.
FASTENERS & MISC. COMPONENTS
(not shown in actual size)
•
STEP 1
HARDWARE & FASTENER LIST
REF # PART # DESCRIPTION QTY
6 40078-000 1/4” Fuel Hose 36”
7 40077-000 3/16” Fuel Hose 34”
8 62999-004 Black Hose Clamp .69” OD 4
9 62999-001 Red Hose Clamp .5”OD 4
10 62999-005 Green Hose Clamp .41” OD 3
11 98435-001 Hose Fitting Elbow 1
12 62409-000 Bushing 1
13 62173-001 5/16” Self-Tapping Screw 2
14 98590-003 1/8” - 5/16” X 1/4” - 7/16” Hose Reducer 1
15 40079-000 5/16” Fuel Hose 8”
6
7
11
13
14
15
12
8
9
10
