SETUP & INSTALLATION
8
6. Push the Blue Tubing from the System Faucet into the Outlet
Connector located on Intelligent Monitor ™ . (fig. Q)
7. Using the other piece of Blue Tubing provided, push one end of
the Tubing into Outlet Connector located on Lid Assembly, and
remaining end of Tubing into the Inlet Connector located on
Intelligent Monitor ™ . (fig. R)
8. Insert Cable Connector into Cable Port located on Intelligent
Monitor ™ , then insert Battery Shuttle into Battery Port located
on Intelligent Monitor ™ . (fig. S) The LED Indicators located on
the System Faucet will flash GREEN, YELLOW and RED five
times. This resets the rated capacity counter to zero gallons.
Do NOT remove Battery Shuttle until it is time to replace the
Filter Cartridge. Removing Battery Shuttle prematurely may
result in a loss of data.
9. Slowly turn your cold water supply “ON” and check for leaks.
10. Turn System Faucet “ON”. Water will begin to fill the Filter Housing.
Once water begins to flow from the System Faucet, the GREEN
LED Indicator will begin flashing to indicate peak operational
performance. Check to see that all hose, clamp and housing
connections are tight and do not leak.
11. Allow System to flush into sink for 15 minutes. This removes
any fine, black carbon particles left over from the manufacturing
process, expels trapped air and conditions the Filter Cartridge for
normal use. (This water may be used to water plants.)
Congratulations! Your new WaterChef ® Filtration System is ready!
Outlet
Connector
Blue Outlet
Connector
Inlet
Connector
Cable Battery Shuttle
Intelligent
Monitor ™
Blue Tubing
(from System
Faucet)
Blue Tubing
CAUTION
Be sure to leave enough Tubing length so that it does not kink or bend sharply.
IMPORTANT
Repeat flushing procedure each time a new Filter Cartridge is installed.
Q
R
S
