Vizualogic RoadTrip GPS Mirror User Manual
Page 9
1
Mirror
Standard Mirror or AutoͲDimming Mirror
2
V2
Video Input#2
3
M
Switch from Video mode to GPS mode
4
Press and hold to turn on/off the device
5
S
Mute or Turns On/Off AutoͲdimming Functions
6
V1
Video Input #1
7
MIC
Bluetooth Microphone
8
Touch Screen
4.3Ͳinch touch screen
9
SD Card Slot
Supports up to 8GB SD card
10
Video Input (1)
Video Input (v1 button selected)
11
Video Input (2)
Video Input (v2 button selected)
12
Bracket Chassis
Attach Vehicle Specific Bracket Here
13
Car Camera Input
Rear Camera Input Port
14
Battery (yellow)
12V+ Constant power supply
15
ACC (Red)
12V+ ACC power supply
16
Gnd(black)
Chassis ground
17
Camera Trigger Line(Green)
Trigger for backup camera signal switching
18
Fuse
Serviceable fuse
NO.
Name
Description
