VTR8300 Series

2

Installation Guide

Viconics Technologies Inc.

|

9245 Langelier Blvd.

|

St.-Leonard

|

Quebec

|

Canada

|

H1P 3K9

|

Tel: (514) 321-5660

|

Fax: (514) 321-4150

028-0414-02

www.viconics.com

|

[email protected]

February 2015

©

2

01

5 V

ic

onic

s T

ec

hno

lo

gi

es

Inc

. A

ll r

ig

ht

s r

ese

rv

ed

.

DISClaImERS

• The VTR8300 series controller is only to be used in conjuction with the VC3000 line voltage switching relay pack. Together they are

used as operating controls for high voltage fan coil units.

• If replacing an existing Line Voltage FCU Controller, label the wires before removal of the controller.
• Electronic controls are static sensitive devices. Discharge yourself properly before manipulating and installing the Terminal Equipment

Controller. A short circuit or wrong wiring may permanently damage the Terminal Equipment Controller or the equipment.

• All VTR8300 series controls are designed for use as operating controls only and are not safety devices. These instruments have

undergone rigorous tests and verification prior to shipping to ensure proper and reliable operation in the field. Whenever a control
failure could lead to personal injury and/or loss of property, it becomes the responsibility of the user / installer / electrical system
designer to incorporate safety devices (such as relays, flow switch, thermal protections, etc…) and/or an alarm system to protect the
entire system against such catastrophic failures. Tampering with the devices or unintended application of the devices will result in a
void of warranty.

• If the equipment is used in a manner not specified by the manufacturer, the protection provided by the equipment may be impaired.
• These devices are not serviceable and must be returned to the supplier.
• A switch or cicruit breaker must be installed. It must be suitably located, easily reached and marked as the disconnecting device.

VTR8000 Controller

VC3000 Relay Pack

ImPORTaNT SymbOlS

Products marked with this symbol state that the manuals must be consulted in all cases to any hazards.

This product has been tested to the requirements of CAN/CAS-C22.2 No. 61010-1, second edition, including Amendment 1,
or a later version of the same standard incorporating the same level of testing requirements.

Alternating Current

Direct Current

Equipment protected throughout by DOUBLE INSULATION or REINFORCED INSULATION
