3
Specifications
Introduction
Operational
Flow controls
Output concentration range Fractional ppb to hundreds of ppm
Carrier flow rate (nominal) 100 – 400 sccm
Dilution flow rate range(nominal)* 1 -20 SLPM *(depending on model)
Dilution flow accuracy +/- 1% of Setpoint from 20%-100% of full scale,
+/- .2% of full scale between 2% - 20% of range
Operating temperature range 10° to 50°C (50° - 122°F)
Permeation Chamber
Temperature range* 30° - 110°C *(Must be at least 2°C above ambient)
Temperature setpoint accuracy +/- 0.05°C (NIST-Traceable) from 30°C -110°C
Temperature setpoint repeatability +/- 0.01°C at any fixed ambient temperature
Temperature equilibrium time 1.5 hours for highly dynamic changes
Chamber size Accepts devices up to 23.5 cm X 1.6 cm diameter
Modes (Auto or Manual) Span Out
Operating Duty Cycle Continuous
Environmental
Operating noise emission 45 to 50 dBA
Ambient operating temperature 20°C to 35°C
Operating humidity 0-95% relative humidity
Storage temperature 10° C to 40°C
Storage humidity 0 – 50% relative humidity
Power requirements
Voltage, frequency, power 100-240 VAC, 50/60 Hz, 150 Watts maximum
