Model Number Breakdown
Base Model
23 - Basic gas generator, continuous supply
34 - Intermediate generator, with zero and span functions
45 - Multiple modes, with zero, span, and bypass functions
50 - Two chambers (A and B), with selector for zero, A, B, or A+B
Flow Control and Metering Methods
0 - Manual/pneumatic control, mechanical/pneumatic metering
5 - Electronic control, digital numeric metering
Basic Plumbing Configuration
0 - No pump, single gas supply inlet
1 - No pump, dual gas supply inlets (carrier & dilution)
2 - Internal pump, no gas stream bypasses 1
3 - Internal pump, single gas stream bypass (carrier) 1
4 - Internal pump, single gas stream bypass (dilution) 1
5 - Internal pump, dual gas stream bypasses (carrier & dilution) 1
Dilution Gas Flow Capacity
3 - 1 L/min
4 - 2 L/min
5 - 5 L/min
6 - 10 L/min
7 - 15 L/min
8 - 20 L/min
9 - special flow
Carrier Gas Flow Capacity
A - 80 cc/min
B - 175 cc/min
Rack Mount
R - Slide-mount package with pull handles (19")
Additional Options
C - 220V/50Hz operation
D - Flowmeter with fully calibrated dual floats; second float
gives full scale reading at ~30% capacity 2
M - Constructed for use with moisture and moisture-sensitive compounds 3
S - Any non-standard option (contact factory for quote)
Chamber Material
I - 150 Inertium
N - HC-276 (for HCl, HF, and Cl)
Model - - -
1 Internal pump not available on Model 500/505, or on any model constructed for use with moisture (Option M)
2 Available only on models with manual/pneumatic flow control
3 Available only on models with electronic flow control
Name
PFA
FC
CSU
PD
LF
Description
Low-pressure-drop particulate filter assembly for Dynacalibrators with
an internal pump which will be operated in dusty environments
Replacement filter cartridge for PFA
Replacement charcoal scrubber unit
Replacement pump diaphragm
Replacement 5 micron line filter element, with gaskets
Product No.
50-02-102
07-10-016
50-02-041
07-05-001
07-13-005
Accessories
