QuickSpecs
Compaq ProLiant DL580
DA-10635
North America — Version 13 — December 18, 2000
2
Standard Features
Proc es sor
Intel Pentium III Xeon processor 700 MHz
(Note: One or two processors ship standard depending on model.)
Ca che M emor y
2-MB level 2 writeback cache per processor standard
One of the following
1-MB level 2 writeback cache per processor standard
Upgrad abi li ty
Upgradable to quad processing
Support for future processor upgrades
Memor y
Standard
512 MB (PC100-MHz Advanced ECC SDRAM Memory)
Maximum
16 GB
Note: Advanced ECC Memory Technology protects the data even in the event of an entire SDRAM component
failure. Embedded in the chipset design, this feature allows the use of Industry-Standard Registered DIMMs.
Ne twor k Con trol le r
Integraged Compaq NC3134 Fast Ethernet NIC 64 PCI Dual Base 10/100 in a slot (upgradable to Gigabit)
Expan sion Slo ts
I/O (Total)
6, 5 available
64-bit/66-MHz PCI Hot Plug
2, 1 available
64-bit/33-MHz PCI Hot Plug
2, 2 available
64-bit/33-MHz PCI
1, 1 available
Non-Hot Plug
32-bit/33-MHz PCI
1, 1 available
Non-Hot Plug
Stor age Con tro ll er
Integrated Smart Array Controller (supports Internal RAID 0, 1, 0+1, 5 and external tape devices)
Note: The Integrated Smart Array Controller is embedded on the system board.
Stor age
Diskette Drives
1.44 MB
CD-ROM
High Speed IDE CD-ROM Drive (slim line)
Hard Drives
None
Maximum Internal Storage
145.6 GB (4 x 36.4 GB 1
″
drives) (internal hot plug drive cage)
Int er fa ce s
Parallel
1
Serial
1
(Note: You can configure a second serial device to your ProLiant DL580 server
by installing the auxiliary serial connector that ships with the server. The auxiliary
connector attaches to a serial port B on the peripheral board and exits the rear of
the server through the auxiliary serial knockout located directly above the
redundant power feeds.)
Pointing Device (Mouse)
1
Graphics
1
Hot Plug Keyboard
1
External Wide Ultra2 SCSI
1
Network RJ-45
1
Graphi cs
Integrated 1280 x 1024, 256 color on PCI local bus, 2-MB video memory
Form Factor
Rack (4U = 7
″
), ships with sliding rails and cable management
Compaq So ftwar e
Compaq Insight Manager™
The comprehensive system management tool that monitors the operation of
Compaq servers, workstations and clients
Compaq SmartStart™
The server configuration and software integration tool from Compaq
Array Configuration Utility (ACU) Same easy to use yet powerful graphical user interface (GUI) configuration utility
with Smart Array Controllers
and easy to navigate wizards for all Smart Array Controllers
