Specifications
Inputs
Processor: Eight inputs corresponding to left, center, right, surround
left, surround right, back surround left, back surround right and subwoofer.
Input impedance is 10k
.
Power Amplifiers: Eleven inputs corresponding to left hi and lo, center hi
and lo, right hi and lo, surround left, surround right, back surround left, back
surround right and subwoofer. Input impedance is greater than 50K.
Controls
Front Panel: Individual push button switches for each input
channel toggle on and off so that channels may be monitored in
any combination. An LED indicator illuminates when the corresponding
channel is selected. A volume control sets the speaker output level and works
independently of the front panel VU bargraph meter. A push-button switch
with corresponding LED switches monitoring between the Processor and
Amplifier inputs. A 12-segment bargraph VU Meter indicates the input level
from -40 to +3 VU.
Rear Panel: Three trimpots adjust the processor, amplifier and
VU meter input levels.
Power Requirements
100-240VAC, 50-60Hz, 32 Watts
Construction
The CM Series Monitor is constructed of steel to minimize hum
pickup and noise radiation. The overall size of the unit is 3.5"
x 19" x 9.625". The CM Series is designed to mount in a standard rack
frame or cabinet.
CM-680
Weight: 10 lbs. 2 oz. (4.63 kg)
Shipping weight: 16 lbs. (7.26kg)
Shipping Size: 22” x 22” x 6” (558.8 x 558.8 x 152.4 mm)
