- 11 -
CM Series I
NSTRUCTION
M
ANUAL
Ultra Stereo Labs, Inc.
Speaker Crossover Frequency Time Delay
JBL 4675D 500Hz 1.8ms.
JBL 4670 800Hz 0.7ms,
JBL 5671 330Hz 1.4ms
JBL 5672 297Hz 1.8ms.
JBL 5674 297Hz 1.8ms
EV TS940 800Hz 0.7ms.
EV TS992LX 500HZ 1.8ms.
EV 9040 500Hz 1.8ms
EV Variplex 330Hz 1.4ms
EAW CB2591 500Hz 1.8ms
EAW CB259 800Hz 0.7ms
EAW CB253 350 0.7ms
Setting DIP Switches
Settings for typical loudspeakers
Channel
Configuration
Processor
JSD-80/XD-10P CP-650
L, C, R, SW plus Ls/Rs channels
L, C, R, SW plus Ls/Rs, Bsl/Bsr
“EX” channels
L, Lc, C, Rc, R, SW plus Ls/Rs
channels
L, Le, C, Re, R, SW plus Ls/Rs
channels
1-4 ON
1-4 ON, E-H ON
1-4 ON, E-H ON
1-4 ON, E-H ON
1-4 ON
5-8 ON, A-D ON
N/A
1-4 ON, E-H ON
NOTE:
Lc & Rc are full band channels, Le/Re are low frequency channels
