pT2-500 Microphone Preamplifier OPERATION MANUAL
Version 1.0 11 ©2010 TRUE SYSTEMS
SPECIFICATIONS*
Frequency Response
@ 40dB gain (-3 dB)
1.5 Hz – 600 kHz
THD+N
@ 40dB gain,+26 dBu out, 20Hz to 20kHz BW
0.0004%
Intermodulation Distortion
SMPTE/DIN 4:1 (60Hz/7kHz), @40dB, +26dBu
0.0009%
Noise (E.I.N)
Rs = 0 Ohms
-133 dB
CMRR
@40dB gain, Vcm = +10dBu
85 dB
Slew Rate
50 V/us
Microphone Input 1x balanced (XLR-type)
(via card edge connector)
Maximum Input Level
+ 22 dBu
Input Impedance
5.5 kOhm
Gain +6 to +58 dB (LO gain)
+18 to +70 dB (HI gain)
Instrument Input (DI)
FET discrete circuit 1x unbalanced, (jack type)
(IN jack on front panel)
Maximum Input Level (DI) +11 dBu
Input Impedance (DI)
2.5 MOhm
Gain (DI) -14 to +38 dB (LO gain)
-2 to +50 dB (HI gain)
Output 1x balanced (XLR)
(via card edge connector)
1x unbalanced (TS jack)
(THRU jack on front panel)
Output Impedance
100 Ohm
Maximum Output Level
+29 dBU
Power Requirements ±16 VDC, +48 VDC
(power supply - 500 format rack)
(via card edge connector)
Power Consumption 65 mA = 1.04 W (±16V)
2 mA = 0.01 W (+48V)
Dimensions 1.5“ x 5.25“ x 6.05“ (W x H x D)
38.1 x 133.4 x 153.8 mm
Weight
1.4 lbs. (0.64 Kg)
*Typical performance. Specifications subject to change without notice.
