Whisper Lift II
www.touchstonehomeproducts.com 800.215.1990
20
Assembling Component Shelf – cont
2. Using the 2 remaining small nuts and bolts (D), attach the shelf brackets (C) to the lift. The shorter end of the
shelf bracket attaches underneath of the shelf.
3. When completed, attach the component shelf to the lift using the 2 large hex bolts (E) and nuts provided.
Shelf Brackets
Shelf Brackets
Assembled Component
Shelf
Component Shelf
Attached to Lift
