Setting Adjustable Roller Height
Each Whisper Lift II comes with an adjustable roller assembly that allows you to set the maximum height of the
lift.
Tools Needed:
- adjustable wrench or 4mm socket wrench
- size 4 metric hex wrench
Instructions:
1. Raise the lift to a height that is comfortable for you to work at.
2. The adjustable roller is held in place by 2 4mm hex screws on either side of the lift. Using the size 4 metric hex
wrench and adjustable wrench/socket wrench, remove all 4 screws holding the adjustable roller in place.
3. Raise the adjustable roller to the desired level and refasten the adjustable roller to the lift using the screws/nuts
removed in step 2.
4. Adjust height of adjustable roller as needed so that lid of cabinet closes flush.
