Digital Stereo Mixer M-864D

External Control Protocol – TCP/IP

Ver.2.0.0 Dec.2 /2013

Summary

The External Control protocol described in this document is designed for use of controlling the M-864D from

a personal computer or remote controller.

This spec sheet applies to the M-864D firmware of version 2.0.0 or later.

Settings that can be controlled are as follows:

Channel Fader Gain

Channel ON/OFF

Line(Stereo) Select

Input Matrix Assignment

Input Matrix Crosspoint Gain

Output Matrix Assignment

Preset Memory Load

Preset Memory Store

LOCAL/UNLOCAL Status Change

Level Meter Status Notification Start/Stop

Auto Status Notification Start/Stop

If necessary, the M-864D’s activation can be checked or setting values read by using the following

commands:

Status request (reading of the M-864D’s setting value)

Status Information

M-864D connection establishment status (output from the M-864D at the time of

connection establishment)

Level Meter Status (output from the M-864D at the time of level meter status changed)

ZM Remote Controller Connection Status (output from the M-864D at the time of ZM

remote controller connection status changed)

Contact Input/Output Make/Break Status (output from the M-864D at the time of

Contact I/O make/break status changed)

[Note]

When connecting the remote controller to the M-864D by way of this protocol, set the M-864D’s Using port

as follows:
