7.3. Example of External Equipment Connections
AC Mains
Dynamic Microphone
Dynamic Microphone
Dynamic Microphone
Radio Tuner, CD Player, or Cassette Deck Player
100 V Line
Column Speaker with
Matching Transformer
100 V Line
Horn Speaker with
Matching Transformer
12 V DC Battery
8. VOLUME CONTROL SETTINGS
Output levels are adjustable with individual volume controls. For music play or announcement, adjust the
corresponding volume control so that the signal output is not distorted.
Note that the sound quality is downgraded when the output is distorted.
