* 1 Distance between barriers on the above screw terminals: 7 mm (M3 screw), 9 mm (M4 screw)
* 2 0 dB = 1 V
* 3 Can be transformer-balanced with the addition of optional IT-453A input transformer.
* 4 LINE 1 and LINE 2 outputs can be interlocked with ZONE 1 and ZONE 2 speaker selectors, respectively.
* 5 330 Ω (A-1803), 167 Ω (A-1806), 83 Ω (A-1812)
* 6 Operation when activated can be selected from the following: Turning ON the unit's power (factory-preset) or OFF.
Note: The design and specifications are subject to change without notice for improvement.
• Accessories
AC power cord ................................................... 1
Terminal cover ................................................... 1
Terminal cover mounting screw (M4 x 8) ........... 2
• Optional products
Rack mounting bracket: MB-25B
Volume control cover: YA-920
Input transformer:
IT-453A (Available as a service part, whose part code is "114-03-118-30.")
Perforated panel: PF-013B
Model No. A-1803 A-1806 A-1812
Priority EMERGENCY: Overrides other inputs
TEL:
Overrides other inputs except 'EMERGENCY', ON/OFF
selectable with switch setting
MIC 1: Overrides other inputs except 'EMERGENCY' and TEL',
ON/OFF selectable with switch setting
Operating Temperature –10°C to +40°C
Finish Panel: ABS resin, black, hair line
Case: Steel plate, black
Dimensions 420 (w) x 107.7 (h) x 367 (d) mm
Weight 8.1 kg 9.4 kg 12.6 kg
133-12-846-6C
URL: http://www.toa.jp/
Traceability Information for Europe (EMC directive 2004/108/EC)
Manufacturer:
TOA Corporation
7-2-1, Minatojima Nakamachi, Chuo-ku, Kobe, Hyogo,
Japan
Authorized representative:
TOA Electronics Europe GmbH
Suederstrasse 282, 20537 Hamburg,
Germany
