ThermoWorks RT600C SUPER-FAST POCKET THERMOMETER - Manual

ThermoWorks, Inc.
Utah, U.S.A.
Ph: 801-756-7705
Fax: 801-756-8948
www.thermoworks.com
• -40 to 302°F Range
• Dishwasher Safe to 190°F
• IP65 Water Resistant
• On/Off Switch
• Max/Min Memory
• °C/°F Switchable
• Includes Pocket Clip
Instrument Operation
Press the button to activate the thermometer. The unit will turn off automatically
after 1 hour to save battery life.
Insert the stainless steel probe to the desired depth. The measured temperature will
be shown on the LCD display within 5 to 6 seconds.
To Select ˚F or ˚C
Press the ˚C/˚F button on the back of the thermometer to select the desired
temperature unit.
Using MIN/MAX
Press the MAX/MIN button to read the last highest / max temp measured.
Press once more to read the last lowest / minimum temperature measured.
Press once more to return to normal display.
Press and hold the button for three seconds then release to reset the memory.
MAX and MIN are reset when the unit is powered off.
Battery Installation
Replace the battery when low battery symbol 'Bat' flashes.
Replace with a 3 volt, type CR2032 button cell battery or equivalent.
Use a screwdriver of suitable size to open the battery cover on the back.
Install the battery observing the correct polarity.
Close the battery cover.
Care and Cleaning
Clean the probe immediately after each measurement to avoid cross contamination.
If there is erratic operation, press the RESET button on the back of the thermometer.
Do not expose the entire thermometer to temperatures over 190˚F (88˚C). Do not
leave inside ovens. Not submersible.
Technical Support
For warranty, service, and technical assistance, please contact ThermoWorks’
Technical Support at (801) 756-7705 or email at [email protected].
For additional cooking tips and doneness temperatures, and to see the full line of
ThermoWorks tools, visit our website at www.thermoworks.com.
Specifications
Measuring Range -40 to 302˚F (-40 to 150˚C)
Accuracy ±0.9˚F (±0.5˚C ) between 14 to 212˚F (-10 to 100˚C),
otherwise ±2.7˚F (±1.5˚C)
Display Resolution 0.1°
Response Time Approx. 6 seconds from ambient to 32˚F
Auto Off After 1 hour
Display Size 0.35 H x 0.71 W inches (18 W x 9 H mm)
Digit Size 0.28 H x 0.14 W inches (3.5 W x 7 H mm)
Probe Size 0.097 dia. x 4.8 L inches (2.5 dia. x 125 L mm)
Probe Tip 0.07 dia. x 0.67 L inches (1.7 dia. x 17 L mm)
Minimum Immersion Approx. 0.25 inch (6.4 mm)
Water Resistance IP65
Battery 3 volt, type CR2032 or equivalent x 1 piece (included)
Battery Life 5,000 hours continuous use
Product Size 7.9 H x 1.02 W x 0.8 D inches
(203 H x 26 W x 20 D mm)
Operating Range 32 to 190˚F (0 to 88˚C)
RT600C
Super-Fast
Waterproof
Pocket
Thermometer
P-10-002-01-d
