17
CHANNEL ASSIGNMENTS
This function allows transmitter channels to be re-assigned to different channels before
being sent to the receiver. This can be useful for models having unusual confi gurations.
Some small electric fl ight models use only elevator, throttle,
and rudder channels (not aileron). Here, it’s often preferred
that the rudder be controlled with the opposite stick (right
stick for Mode 2 confi gurations). Such channel re-assignment
can be done in this screen.
Determine which Tx control input on the left (TXCH) should
control which output channel at the receiver as shown on
the right (OUTPUT). Move the box to the desired input control
on the left. Press ENTER then
or to fi nd the output
channel as desired. Press ENTER when fi nished.
WARNINGS
Warnings can be set to alert you of undesirable switch or
throttle positions when the radio power switch it fi rst turned
on. For example, if the throttle is at full when turn on the radio,
you would see and hear an alarm. The alarms shown can be
set to ACT (active) or INH (inhibited).
THRO POS: The warning sounds
when the throttle stick is over 25%.
Clear the alarm by moving the stick
down. Note: If you are in heli mode,
and you have an Idle-up programed,
This alarm will also sound to indicate
that you have an Idle up switch active.
THRO CUT: The warning will sound
when this switch is on. Turn off the
switch to clear the alarm.
THRO HOLD: The warning will sound
when this switch is on. Turn off the
switch to clear the alarm.
CHANNEL ASSIGNMENTS
TXCH OUTPUT
CH1 Output1 ->
CH2 Output2 ->
CH3 Output3 ->
CH4 Output4 ->
WARNING SET
THRO POS:INH
THRO CUT:ACT
THROHOLD:ACT
5.1V
>Oxo100E 02
THR POS.
CONTINUE? YES
