12
Elevator arm and spring: The black plastic arm and spring
must be re-located from the elevator gimbal to the opposite
gimbal. Using a pair of needle nose pliers or hemostats,
carefully grip the end of the spring which is looped over
the end of the black plastic arm and gently lift it off the arm.
Then slide the spring towards the center of the gimbal to
remove it from the gimbal. Set the spring aside.
Raise the plastic arm to a vertical position. Slide the arm
towards the center of the gimbal to remove it from its
mounting pin.
Rotate the arm 180 degrees to mount it to the opposite
gimbal. While in the vertical position, slide the arm over the
mounting pin on the opposite gimbal. Lay the arm down
across the gimbal.
Gripping one loop on the end of the spring with pliers or hemostat, carefully lower the
opposite loop of the spring into the gimbal to slide it over the appropriate mounting pin.
With the spring holding onto the pin inside the gimbal, carefully stretch the spring and
hook the loop over the end of the plastic arm. Confi rm the arm and spring are mounted
properly by moving this stick and ensuring all movement is smooth but with resistance
from the spring.
Close the transmitter as explained in the CASE SEPARATION AND ASSEMBLY section.
CONTRAST
Adjust the LCD’s contrast level for optimum viewing.
BEEP VOLUME
Adjust the loudness of the radio’s beeper as desired. This volume setting affects all
tones that are emitted from the radio including while making adjustments such as trim
adjustments, programming changes, etc. Beep volume for all alarms is not adjustable.
BATTERY ALARM
An alarm will sound and the display will show “LOW BATTERY” when the Tx battery’s
voltage drops to the level shown in this setting. Do NOT set this value too low, as the
radio could lose power very rapidly as the battery nears full discharge and cause a loss
of control of the model. Land the model immediately once this alarm has sounded!
Battery type
Nickel-Cadmium (NiCd)
or Nickel-Metal
Hydride (NiMH)
4.00V 4.40V 4.00V
Alkaline 4.00V 4.00V 3.60V
Default Recommended Minimum
Once all functions in this menu are set, press ESC to return to the home screen.
