19. Unscrew the nut securing the bracket on the side
burner orifice. (See Fig. 16)
20. Use a wrench to remove the side burner orifice
from the flex line and replace it with the NG orifice
provided in the kit. (See Fig. 17)
21. Use the nut removed in step 19 to secure the
bracket onto the side burner orifice. (See Fig. 16)
22. Use the two screws removed in step 18 on page 4
to secure the bracket in position. (See Fig. 15 on
page 4)
23. Attach the left side shelf onto the grill head
assembly, and tighten the four (4) screws with a
wrench. (See Fig. 5 on page 2)
24. Attach the side burner shelf onto the grill head
assembly, and tighten the four (4) screws with a
wrench. (See Fig. 4 on page 2)
25. Reinstall the igniter module in position and feed
the battery with negative (-) end in first. reconnect
the igniter wires to the igniter module. It does not
matter which terminal tab is used when connecting
igniter wires.
26. Attach the NG hose provided in the kit to the side
burner valve. (See Fig. 1 on page 2)
5
CS812 Natural Gas Conversion Instructions
Fig 16
Fig 17
Nut
Bracket
Side burner orifice
