13. Push the front control panel back in position,
make sure the orifices of the valves insert into
the main burner tubes. Then use the four (4)
screws remvoed in step 6 on page 3 to secure
the front control panel in position. (See Fig. 11)
14. Remove the six (6) screws securing the rear IR
cover and wind shield in position. (See Fig. 12)
15. Take off the wind shield, grasp the rear infrared
cover and remove it from the grill. (See Fig. 13)
16. Use a wrench to remove the LP orifice on the
rear IR burner and replaced it with the NG orifice
provided in the conversion kit. (See Fig. 14)
17. Use the four (4) screws removed in step 14 to
reinstall rear IR cover in position, then use the
other two screws to reinstall the wind shield.
(See Fig. 12)
18. Open the side burner door, remove the two
phillips pane head screws holding the side burner
orifice bracket in position. (See Fig. 15)
4
Fig 13
Fig 14
Fig 15
CS812 Natural Gas Conversion Instructions
Phillips pan
head screws
Fig 11
Control valve orifice
Main burner tube
Fig 12
Wind shield
Rear IR cover
Rear IR orifice
