Connection ports – StarTech.com R300WN22OP5E User Manual
Page 7
Instruction Manual
4
Interface
Description
Reset Button
Press continually for 5 ~ 10 seconds to reset the device to
factory defaults
LAN 1
Allows LAN connection through a Category 5 (or better)
cable. Supports auto-sensing for 10/100Mbps speeds and
half/ full duplex
LAN 2
Allows LAN connection through a Category 5 (or better)
cable. Supports auto-sensing for 10/100Mbps speeds and
half/ full duplex
Connection Ports
Reset Button
LAN 1
LAN 2
Ground
Note: The reset button on the PoE injector will only work if plugged into the
LAN 1 port.
