Instruction Manual
5
Specifications
Ports 1
Industry Standards
IEEE 802.3af PoE, IEEE 802.3at PoE+
IEEE 802.3 10Base-T, IEEE 802.3u 100Base-
TX, IEEE 802.3ab 1000Base-T
Regulatory Approvals
EMS: EN61000-6-2, EN61000-4-2 (ESD),
EN61000-4-3 (RS), EN61000-4-4 (EFT),
EN61000-4-5 (Surge), EN61000-4-6 (CS),
EN61000-4-8 (PMF, Magnetic Field)
Shock: IEC 60068-2-27
Freefall: IEC 60068-2-32
Vibration: IEC 60068-2-6
Connector Type(s)
2x RJ-45 Female
1x Terminal Block (6 Wire)
Max Distance 100 m / 330 ft
Maximum Data Transfer Rate 1Gbps
Power Output
Standard PoE+: 30 Watts max
Non-Standard PoE: 60 Watts max
Color Black
Enclosure Type Steel
Dimensions (LxWxH) 142 x 106 x 39 mm
Product Weight 720 g [25.42 oz]
Input Voltage 20 - 57 DC – Terminal Block
Humidity 5-95% RH (Non-Condensing)
Operating Temperature 0°C to 60°C (32°F to 140°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
