Instruction Manual

7

Specifications

Video Signal

VGA (RGBHV): 0.7Vp-p or 1Vp-p with sync

75 Ohm

External Connectors (Input)

4 x DE-15 VGA female

4 x 3.5mm Audio mini-jack female

1 x DB9 female

1 x DC Power female

External Connectors (Output)

1 x DE-15 VGA female

1 x 3.5mm Audio mini-jack female

LEDs

1 x Power

4 x Port Selection Indicator

Maximum Video Resolution

1920 x 1200 / 1080p

Video Bandwidth

650 MHz (-3dB)

Differential Gain

0.05%

Differential Phase

0.05 degrees

Switching Methods

Front Panel Buttons, IR Remote Control,

RS232 Serial

Power Consumption

5W (max)

Power Adapter

5VDC, 2600mA, center positive

Enclosure Material

Aluminum

Dimensions (LxWxH)

292.0mm x 73.0mm x 44.0mm

Weight

1500g
