Page 5
Instruction Manual
2
Hardware Guide
Local Unit - Front View
ST124UTPEA
ST128UTPEA
ST124UTPEA
ST128UTPEA
1
Input Power Jack
2
VGA Output (HD-15 Female Connector)
3
VGA Input (HD-15 Female Connector)
4
AUDIO Input
5
MIC Input
6
MIC GAIN - adjust volume of microphone
7
CAT5 OUT (RJ-45 Connectors): ST124UTPEA x 4
ST128UTPEA x 8
Power LED
1
2
3
4
5 6
7
*ST124UTPEA shown
