StarTech.com ST12MHDLANRX - Manual (Page 8)

Instruction Manual
5
Specifications
Maximum Digital Resolutions 1920x1200 @60Hz
Supported Resolutions 1920 x 1200 (1080p)
Wide Screen Supported Yes
Audio Specifications Stereo Sound
Interface HDMI®
Cabling Cat 5e UTP or better
Audio Yes
Rack-Mountable Yes
Daisy-Chain Yes
Receiver Connectors
1x HDMI® (19 pin)
1x RJ-45
Power Adapter Input Voltage 100~240V
Power Adapter Input Current 0.4 A
Power Adapter Output Voltage 5 DC V
Power Adapter Output Current 2 A
Center Tip Polarity Positive
Plug Type M
Factory Default Setting
1. Disconnect the power cable from the Transmitter/Receiver.
2. Hold down the F1 button
3. Reconnect the Power while holding down the F1 button
4. Release F1 button after the power has been reconnected for 17 seconds (the Link
OK POWER LED flashes green and blue)
5. Reconnect the Power again.
