S C 3 / 2 0 F E A T U R E S
CHARGE REGULATION
•
20 amp charge current, 12 volt
•
Switching shunt, pulse charging
•
Adjustable charging set-points
•
Temperature compensation (option)
LOW VOLTAGE LOAD DISCONNECT (LVD)
(option)
•
10 amp LVD Relay
DESIGN FEATURES
•
100% solid state charge control
•
Designed for rugged mobile use
•
Over-current protection - Battery fuse
•
Reverse leakage protection - Blocking diode
•
Reverse polarity protection
•
Lightning protection
•
Input noise suppression
•
Low power consumption
MONITORING
•
Efficient Liquid Crystal Display (LCD)
-Measures battery voltage
-Measures charging current
-Measures second current with external
shunt (external shunt supplied
separately)
-Indicates charging set-point
•
Charging light
•
Charged light
•
Low Voltage light
MOUNTING OPTIONS
•
Flush mount
•
Knock-out box available for wall mounting
(4x7 BOX accessory)
