S
PECIFICATIONS
NOMINAL
MODEL
VOLTAGE
BS1 - (Low-voltage Load Disconnect)
12
BS6 - (Generator Start)
24
36
48
PART NUMBERING KEY
EXAMPLE:
Model
Nominal Voltage
BS1 - 12
PARAMETERS
UNITS
NOMINAL VOLTAGES
12 v
24 v
36 v
48 v
System Voltage, Max
(Volts)
17.0
34.0
51.0
68.0
Load Current, Continuous (1)
(Amps)
25
25
15
15
Load Current, Max (60 seconds) (2)
(Amps)
30
30
19.5
19.5
System Voltage, Max.
(Volts)
17.0
34.0
51.0
68.0
Operating Voltage @ Battery, Min.
(Volts)
9.6
9.6
19.2
19.2
Quiescent Current (3)
(Milliamps)
8.2
12
10
10
Current Consumption, Energized
(Load Disconnected / Gen Start) (4)
(Milliamps)
107
116
75
75
Voltage Drop, Typ. (Battery to Load)
(Volts)
.03
.03
.03
.03
Low-voltage Set-point, Factory Set
Load Disconnect , (BS1)
(Volts)
11.5 + .3
23.0 + .6
34.5 + .9
46.0 + 1.2
Generator Start , (BS6)
(Volts)
11.5 + .3
23.0 + .6
34.5 + .9
46.0 + 1.2
Adjust. Low-voltage Set-point Range (5)
(Volts)
10.5 to 12.5
21.0 to 25.0
31.5 to 37.5
42.0 to 50.0
Resumption Voltage, Factory Set
Load Reconnect (BS1)
(Volts)
13.0 + .3
26.0 + .6
39.0 + .9
52.0 + 1.2
Generator Stop (BS6)
(Volts)
13.0 + .3
26.0 + .6
39.0 + .9
52.0 + 1.2
Adjustable Resumption Range, Typ. (5)
(Volts)
12.2 to 14.0
24.4 to 28.0
36.6 to 42.0
48.8 to 56.0
Time Delay, Typ. (6)
(Seconds)
2
2
2
2
Operating Temp. Range
(
°
C)
-20 to 50
-20 to 50
-20 to 50
-20 to 50
Storage Temp. Range
(
°
C)
-55 to 85
-55 to 85
-55 to 85
-55 to 85
Notes:
(1) Non-inductive.
(2) Carry only, Non-switching
(3) Relay unenergized, red L.E.D. off, typical value.
(4) LVD/Gen. start relay energized, red L.E.D. on, typical value.
(5) Higher and lower settings can be reached but are not recommended.
(6) Prevents nuisance disconnects.
