Source Audio Soundblox Pro Bass Envelope Filter User Manual
Page 26
MIDI Channel (Effect Knob)
The label numbers around the effect knob correspond to
MIDI
Channels
1 through 16. Channel 1 is the default. This is a global setting and not
saved for individual presets.
Don’t forget to save the preset after editing the Backpage parameters.
All of the Backpage parameters except the
MIDI
Channel are saved per
preset. To reset values to the default, press both left and right column
select buttons at the same time.
Restoring Factory Settings
The following procedure can be used to restore the factory settings to the
BEF
Pro:
Press and hold the Preset Bank butting while plugging in the
DC
power
supply. Note that this will also delete all saved presets and
MIDI
User
sequences.
26 | Backpage Parameters
PRESET BANK
4-6
1-3
62 125 250 500 1K
(XD) (XC) (OE) (VA) (Q) (EL) (LS)
2K 4K
+12
-12
0
<
>
USER
press both left and right column select buttons at
the same time to reset values to the default.
pRESS
pRESS
pRESS
