PortView Chapter 6. Device Window
6-4
6.2 Using Statistics
Click Statistic button from the sub-group menu to start statistics feature. This supports monitoring and
reset for each device.
 Statistic menu
 Clear All: Clear all displayed data from the current screen. i.e) Rx/Tx Bytes
 Clear Port: Each port can be cleared.
 Scope: One scope window can be opened for each PortView application, and data I/O
monitoring is supported independent to PortView. (6.3 explains this feature further)
 Reset: Each port can be reset.
 Statistics information
 Port: Port numbers for the current device
 Name: Port name
 Tx/RxByte: Transfer/Receive Bytes
 Parity: Number of Parity Errors
 Framing Error: Number of frame Errors
 Overrun Error: Number of overrun Errors
 Reset Count: Reset count
