Lynx 3, Location and identification of parts – Slant/Fin LX-150 User Manual
Page 3
Lynx
3
MODE
DISPLAY
AIR
INTAKE
BOILER
SUPPLY
WATER
BOILER
RETURN
WATER
GAS SUPPLY
VALVE
VENT
BOILER
CONTROL
UNDER THE COVER
TURN
BLACK SCREW
1/4 TURN
THEN LIFT
CONTROL COVER
TO REMOVE
PRESSURE
GAUGE
POWER
SWITCH
TEMPERATURE
DISPLAY
WATER
SUPPLY
SENSOR
SPARK
ELECRODES
(IGNITER)
HEAT
EXCHANGER
WATER
RETURN
SENSOR
BOILER
DRAIN
VALVE
CONDENSATION
TRAP/REMOVAL
CONDENSATE
DRAIN
TEST
PORT
COMBUSTION
BLOWER
GAS
VALVE
AIR INTAKE
HOSE
WATER
HIGH
LIMIT
LOCATION AND IDENTIFICATION OF PARTS
Figure 2. Location and identification of parts (front and side panels are removed) model LX-150 is shown
