2.1.2 main components
1
receiver
3
Bolt
10
charging Handle
17
Barrel
20
gas Block
21
flash Suppressor
23
Trigger
casing
29
Trigger
37
Safety
lever
39
front Take
down Pin
40
rear Take
down Pin
42
Magazine
catch
52
Storage Tube Plug
53
Pistol
grip
56
Hand
guards
40
10 1 56
53 37 42 3 56
20 17 21
29
23 39 52
a
Storage Tube (beneath hand guard)
B
upper Hand
guard
c
Bolt Stop
lever
d
M1913 Sight & accessory
rail
e
Safety
lever
f
optional Sling attachment Point
g
optional Hand
guard
accessory
rails
H
lower Hand
guard
i
Magazine Well
J
Magazine
catch
K
Pistol
grip Storage
a B
c
d
e
f
g H
i
J
K
