SIG SAUER P226 X-Five - Manual (Page 7)

10 USA 11 USA
6 Sight Correction Hinweis
Sight Correction
X
X
X
X
X
X
Fig. 4, point of impact, left Fig. 5, point of impact, deep Fig. 6, rear sight
Handling
Fig. 3
•
Any adjustment to sights should only
be carried out on an unloaded pistol.
6.1 Sight correction for windage
Correction on the micrometer rear sight
Turning the lateral adjustment screw in the arrow direction
(R) results in an impact point shift on the target to the
right.
Turning the lateral adjustment screw against the arrow
direction (R) results in an impact point shift on the target
to the left (Fig. 4).
Notice
6.2 Sight correction for elevation
Correction on the micrometer rear sight
Turning the vertical adjustment screw in the arrow
direction (UP) results in an upward impact point shift
on the target.
Turning the vertical adjustment screw against the arrow
direction (UP) results in a downward impact point shift
on the target (Fig. 5).
4. Check (visually and manually with appropriate aid),
that the round has been ejected and that no other
round is chambered (Fig. 3).
5. Actuate slide catch lever 26. The slide 50 flys forward.
6. Keep the pistol pointed in a safe direction and decock
via the trigger.
7. Empty magazine.
8. Pick up and clean the ejected round.
The pistol is unloaded and decocked. The pistol must be
cleaned after each shooting session (see section 8).
5.8.2 Unloading the pistol, magazine empty, slide open
•
The pistol must not be let out of your hand until the
magazine has been removed and the pistol is unloaded.
Procedure
1. Keep the pistol muzzle pointed in a safe direction.
2. Actuate magazine catch 42 and remove magazine (Fig. 2)
3. Check (visually and manually with appropriate aid),
that the round has been ejected and that no other
round is chambered (Fig. 3).
4. Actuate slide catch lever 26. The slide 50 flys forward.
5. Keep the pistol pointed in a safe direction and decock
via the trigger.
6. Check load status of the magazine.
The pistol is unloaded and decocked. The pistol must be
cleaned after each shooting session (see section 8).
Warning
