2
DXZ535
1. FEATURES
• Flip Down Detachable Aluminum Face & High Visibility Multi-Color LC Display
• Controller for Optional SIRIUS Tuner Modules
• Z-Enhancer Plus for Sound Creation with 3 Adjustment Modes (2-Band P.EQ)
• CeNET with Balanced Audio Line Transmission and Dynamic Noise Cancelling
• 8-Times Oversampling Digital Filter and Dual 1-Bit D/A Converters
English
Contents
1. FEATURES ...................................................................................................................................... 2
2. PRECAUTIONS .............................................................................................................................. 3
Flip Down Panel .............................................................................................................................. 3
Handling Compact Discs ................................................................................................................. 4
3. CONTROLS .................................................................................................................................... 5
4. NOMENCLATURE .......................................................................................................................... 6
Names of the Buttons and their Functions ...................................................................................... 6
Major button operations when external equipment is connected to this unit ................................... 6
Display Items ................................................................................................................................... 8
LCD Screen ..................................................................................................................................... 8
5. DCP ................................................................................................................................................. 9
6. REMOTE CONTROL ..................................................................................................................... 10
Inserting the Batteries .................................................................................................................... 10
Functions of Remote Control Unit Buttons ..................................................................................... 11
7. OPERATIONS ............................................................................................................................... 12
Basic Operations ........................................................................................................................... 12
Radio Operations ........................................................................................................................... 14
CD Operations ............................................................................................................................... 16
Operations Common to Each Mode .............................................................................................. 18
8. OPERATIONS OF ACCESSORIES .............................................................................................. 21
CD/MD Changer Operations ......................................................................................................... 21
TV Operations ............................................................................................................................... 23
9. IN CASE OF DIFFICULTY ............................................................................................................ 25
10. ERROR DISPLAYS ....................................................................................................................... 26
11. SPECIFICATIONS ......................................................................................................................... 28
Thank you for purchasing this Clarion product.
∗ Please read this owner’s manual in its entirety before operating this equipment.
∗ After reading this manual, be sure to keep it in a handy place (e.g., glove compartment).
∗ Check the contents of the enclosed warranty card and keep it carefully with this manual.
∗ This manual includes the operating procedures of the CD changer, MD changer, DVD changer and
TV tuner connected via the CeNET cable. The CD changer, MD changer, DVD changer and TV
tuner have their own manuals, but no explanations for operating them are described.
Sintonizador de FM
Gama de frecuencias:
87,9 a 107,9 MHz
Sensibilidad útil:
9 dBf
Sensibilidad a 50 dB de silenciamiento:
15 dBf
Selectividad de canal alternativo:
70 dB
Separación entre canales (1 kHz):
35 dB
Respuesta en frecuencia (±3 dB):
30 Hz a 15 kHz
Sintonizador de AM
Gama de frecuencias:
530 a 1710 kHz
Sensibilidad útil:
25 µV
Reproductor de discos compactos
Sistema:
Sistema audiodigital de discos compactos
Discos utilizables:
Discos compactos
Respuesta en frecuencia (±1 dB):
10 Hz a 20 kHz
Relación señal-ruido (1 kHz):
100 dBA
Gama dinámica (1 kHz):
95 dB
Distorsión armónica:
0,01%
Audio
Salida máxima de potencia:
208 W (52 W
✕ 4 canales)
Salida media continua de potencia:
16 W
✕ 4, con 4 Ω, de 20 Hz a 20 kHz, 1% de
distorsión armónica total
Acción de control de graves (60 Hz):
±15 dB
Acción de control de agudos (10 kHz):
±12 dB
Nivel de salida de línea (CD a 1 kHz):
2 V
Generales
Tensión de alimentación:
14,4 V CC (permisible de 10,8 a 15,6 V),
negativo a masa
Consumo de corriente:
Menos de 15 A
Impedancia de los altavoces:
4
Ω (permisible de 4 a 8 Ω)
Peso / Unidad fuente:
2,86 lb. (1,3 kg)
Peso / Controlador remoto:
1 oz. (30 g) (incluyendo la pila)
Dimensiones / Unidad fuente:
7" (An)
✕ 2" (Al) ✕ 6-1/6" (Prf)
[178 (An)
✕ 50 (Al) ✕ 157 (Prf) mm]
Dimensiones / Controlador remoto:
1-3/4" (An)
✕ 4-5/16" (Al) ✕ 1-1/8" (Prf)
[44 (An)
✕ 110 (Al) ✕ 27 (Prf) mm]
11. ESPECIFICACIONES
Nota:
• Las especificaciones y el diseño están sujetos a cambio sin previo aviso por motivo de mejoras.
DXZ535
