SWPK INSTALLATION
C
OMPONENTS
The SWPK Assembly comes provided with the following components:
Component Part Number*
Box Cover 5431008
4.57m (15ft) of Tubing, ¼ inch OD 8500516
Filter Cartridge Absorber
Assembly (Replacement) 2800534
Filter Cartridge Assembly
Universal (Replacement) 2800533
Push-to-Connect Fitting 1/8 Inch
NPT, for ¼ Inch OD Tubing 3100795
Push-to-Connect Fitting 1/4 Inch
NPT, for ¼ Inch OD Tubing 3100796
Push-to-Connect Elbow, 1/8 Inch
NPT Pipe, for ¼ Inch OD Tubing 3100791
2 Quick Release Pins 3800633
4 Self-Tapping Sheet Metal
Screws 7360536
Note: All parts numbers may be subject to future revisions.
W ATER T UBING
The SWPK is provided with a length of approximately 4.57 meters (15 feet)
of black, 1/8 inch ID ¼ inch OD tubing. This tubing is intended to be cut by
the end-user. It should be used to connect the SPWK output to the push-to-
connect adaptor on the incubator or humidity cabinet.
A section of the line can also be used to connect the chamber ’s or
i ncubator’s condensation drain to a collection vessel or drainage system.
The end-user is responsible for providing an adaptor and tubing to connect
their water
source to the SWPK’s ¼ inch push-to-connect regulator.
Please see the plumbing diagram on the next page.
Water Source
Regulator
Absorber
Filter
Universal
Filter
Push-to-Connect
Fitting
(Back of the Unit)
Valve
Water Flow
