SWPK INSTALLATION
12) C ONNECT THE C ONDENSATION D RAIN L INE
A section of the included ¼ inch OD tubing can be used to connect the chamber’s or incubator’s
condensation drain to a collection vessel or drainage system.
1. Connect a water line to the press-to-connect fitting located on the back of the unit.
2. Connect the line to a drainage collection vessel or drainage system.
3. The drain is gravity fed. It is important that the receiving receptacle is located below the
level of the incubator’s or cabinet’s drain valve, and the line travels downward. Otherwise
water will collect inside the unit.
Figure 13: Condensation Drain Compression Fitting
F INISHED
Step 12 concludes the SWPK installation procedure.
