background image

Reciprocating Water Bath

15

TROUBLESHOOTING

Should the unit malfunction, use this section to determine the problem and resolution. Troubleshooting
topics include:

Temperature

Mechanical

Other

Table 3. Temperature Troubleshooting

Problem

Possible Cause

Solution

Temperature too high

Main controller set too high

See Setting Main Temperature Control

Main controller failed on

Call customer service.

Wiring error

Call customer service.

Display reads "HI" or "400"+

Probe is unplugged

Call customer service.

Probe is broken or wire to the
sensor is broken.

Call customer service.

Temperature spikes over set
point then settles to set point.

Calibration issue

Recalibrate. See Calibrating the Main
Temperature Control.

Temperature is too low

Over Temperature Safety is set
too low.

See Setting the Over Temperature Safety
Thermostat.

See Setting Main Temperature Control.

Bath temperature not recovered
from water being added.

Wait for display to stop changing.

Unit not recovered from power
failure or being turned off.

Bath will need a minimum of 2 hours to warm up
and stabilize.

Element failure

Compare current draw to data plate.

Main controller failure

Confirm with front panel lights that controller is
calling for heat.

Over Temperature Safety failure

Confirm with Safety light that Thermostat is
operating correctly.

Wiring problem

Check all functions and compare wiring to the
wiring schematic, especially around any areas
recently worked on.

Loose connection

Call customer service.

Display reads "LO" but heating
all the time

Control failure

Call customer service.

Display reads “LO” and not
heating

Sensor plugged in backwards

Call customer service.

Unit will not heat over a
temperature that is below set
point

N/A

Confirm that amperage and voltage match data
plate.

N/A

Confirm that set point is set high enough and that
the Over Temperature Safety is not activated.

Section

8
