SHEL LAB SI9/SI9R Shaking Incubator Operational Manual
10
Copyright © 2007 Sheldon Manufacturing. All rights reserved.
All specifications and features for this product are subject to change without notice.
O O p p e e r r a a t t i i n n g g t t h h e e U U n n i i t t
Control Panel Overview
Before turning the incubator on for the first time, take a moment to familiarize yourself with its controls and
features. Following is an overview of the control panel.
1. Power Switch
 Controls all power to the unit. The switch is lit by a green light when the power is on.
2. RPM Switch
 Activates and deactivates the shaker platform.
3. Timer Switch

Activates and deactivates the timer.
4. Main temperature control
 Displays current chamber temperature.
 Controls temperature set point and calibration.
5. Shaker Speed (RPM) Control
 Displays shaker platform speed.

Controls the rotational speed (RPM) of the shaker mechanism.
6. Oscillation timer
 Permits timed shaking at a preset RPM.
7. Alarms
 Error status lights and an audible alarm immed0iately alert you to deviations of
temperature, RPM, or time.
8. Over Temperature Protection
 Provides backup protection for the main temperature control.
 Keeps the chamber temperature from inadvertently rising above the set point.
