Shellab SRI21D-2 - Manual (Page 22)

22
Wire Diagram
SRI21D-2 (LI15-2) 220-240V
TIMER
DEFROST
TIMER
8250507
1 2
3
14 13
MANUAL
DEFROST SWITCH
7850579
CF
CF
LOW LIMIT
THERMOSTAT
1750538
DOOR SWITCH
INTERIOR LIGHT
CF
9 1
RELAY
CONTACT
FOR 7030536
RELAY COIL FOR
7030536
COMPRESSOR
CONTROL COOLING FAN
4880550
COMPRESSOR
COOLING FAN
4880564
DEFROST
THERMOSTAT
R1
T1
S1
R1
X1
W1
Y1
L3
K3
J3
98
99
CF
CD
CE
WATLOW PM
9660513
RTD
SENSOR
6600520
14 13
RELAY COIL FOR
7030536
RC2
RELAY CONTACT
FOR 7030536 R2
3 4
2 1
1 2
4
OTP 1750862
4 TUBE
ELECTRONIC BALLAST
4660565
FLUORESCENT
FLUORESCENT
FLUORESCENT
FLUORESCENT
2800502
EMI
FILTER
L2
K2
B5
D6
D5
1 2 3 4 5
6 7 8 9
SUB D 9 PIN
CONNECTOR
1650537
4
2
8
6 1 0
5 9
C1
C3
R3 R3
POWER CORD
1800541 CIRCUIT
BREAKER
1100500
CIRCUIT
BREAKER
1100500
POWER SWITCH 7850553
RELAY COIL
FOR 7030520
INTERIOR OUTLET
6100532
STEP DOWN
TRANSFORMER
8350321
½ POWER RELAY
7030520 ½ POWER RELAY
7030520
CHAMBER FAN
4880555
POWER ON LIGHT
4650554
OTL INDICATOR
4650553
HEATING LIGHT
4650554
LIMIT THERMOSTAT
43°C 1750506
SOLID STATE
RELAY
7030523
HEATING ELEMENT
2350536
12VDC
POWER
SUPPLY
6750507
LED LOGO
1750742
RED 22G
BLACK 22G
BLACK BLACK
BLACK
BLACK
BLACK
BLACK
BLACK
BLACK
BLACK
BLACK
BLACK
BLACK
BLACK
BLACK
BLACK
BLACK
BLACK
BLACK
WHITE WHITE
WHITE
WHITE
WHITE
WHITE
WHITE
WHITE
WHITE
WHITE
WHITE
WHITE
WHITE
WHITE
WHITE
WHITE
BLACK
BLUE BLUE
YELLOW YELLOW
GREY
BROWN
BROWN
ORANGE
ORANGE
ORANGE
RED
RED 22G
RED 22G
RED 22G
BLACK 22G
BLACK 22G
BLACK 18G
WHITE 18G
