GRAPHIC SYMBOLS
Your incubator has been provided with a display of graphic symbols which is designed to
help in identifying the use and function of the available user adjustable components.
2.1
Indicates that you should consult your manual for further description
or discussion of a control or user item.
2.2
Indicates "Temperature".
2.3
Indicates "Over-temperature safety".
2.4

C
Indicates "Degrees Centigrade".
2.5
CO
2 Indicates "Carbon Dioxide".
2.6
Indicates "Gas" (CO
2
for this unit).
2.7
Indicates "AC Power ".
2.8
Indicates "Water Jacket Low".
2.9
Indicates "ON/I" and "OFF/O".
2.10
Indicates "Relative Humidity".
2.11
%RH Indicates "Percent Relative Humidity".
2.12
Indicates "Potential Shock Hazard" behind this protective partition.
2.13
Indicates "Protective Earth Ground".
2.14
Indicates “Unit should be recycled” (Not disposed of in land-fill)
