Apr 02

Compuprint PageMaster 402N User Guide

4-21

Cleaning the Printer

4.

Reach into the main paper tray well and rotate the feed roll to the down position, as shown in
the figure below.

5.

Using a soft cloth slightly moistened with plain water, carefully wipe the feed roll.

6.

Rotate the feed roll back into the feed position.

7.

Reinstall the front paper tray.
