Specification
General
Power supply:
12V DC (11V-16V)
Test voltage 14.4V, negative ground
Maximum power output:
50Wx4 channels
Continuous power output:
25Wx4 channels (4 ,10% T.H.D.)
Suitable speaker impedance:
4-8 ohm
Pre-Amp output voltage:
5.0V
Fuse:
15A
Dimensions(WxHxD):
180*100*167 mm
Weight:
1.96kg
Aux-in
≥300mV
Sub-out
5V
FM Stereo Radio
Frequency range:
87.5-108.0MHz
Usable sensitivity:
8dBμ
Quieting sensitivity(S/N=50dB): 12dBμ
Frequency response:
30Hz-15kHz
Stereo separation:
30dB (1kHz)
Image response ratio:
50dB
IF response ratio:
70dB
Signal/noise ratio:
55dB
Note: Specifications and the design are subject to change without notice
due to improvements in technology.
AM(MW) Radio
Frequency range:
522-1620KHz
Usable sensitivity(S/N=20dB):
30dBμ
Components
Mounting bolt (50mm)
1
Mounting collar
1
Wire connector
1
Operating instructions
1
Rubber cushion
1
