9570KL, KR, KT _ _
P o p U p D r a i n
Remove Drain Flange and Drain Plug from pop-up assembly.
Apply a ring of silicone caulking to underside of Drain Flange. Do not use
Insert the threaded end of the assembly up from below and into the pop up
drain hole.
Completely thread the drain body into the Drain Flange and align with the Ball
Rod Hole facing back. Then tighten lock nut from below. Clean excess silicone
with paper towel.
Pop Up Drain Installation (1)
Drain Plug
Drain Flange
Ball Rod Hole
Gasket
Washer
Lock nut
