Spout trim installation – Santec 9550KT-TM User Manual
Page 4
0 4
9550KL, KR, KT _ _
S p o u t
quick connect shank top.
Align the spout and tighten the set screw with the Allen key provided.
Spout Trim Installation
Note: If trim comes later than the roughs, please keep the shank
protector on the spout shank at all times to avoid damages to the unit.
F l a n g e w a s h e r
