Page 31

31
Do not forget to turn on cooking hood while starting to
use the kitchen stove or cooktop. It is necessary for normal
ventilation of the kitchen.
For full ventilation it is necessary to turn off cooking hood
after duration of the period of 15 minutes after cooking.
Hood is equipped with panel control, which is a slider block.
Switching speed of kitchen hood is carried out by slider and
also on and off lighting.
When heating food enough work hood on low speed. For
standard conditions of preparation (cooking and frying for 1-2
burners) used average speed.
High speed is intended to remove from the premises of
a large amount of steam, and the mixed smell of cooking,
working simultaneously all the burners.
Switching speed buttons can be performed in any order.
To turn off the fan, use the button «0».
CONTROL PANEL
1. Turn on high speed of
ventilator.
2. Turn on average speed of
ventilator.
3. Turn on low speed of
ventilator.
4. Turn off the ventilator.
5. Turn on the backlight.
6. Turn off the backlight.
RECIRCULATION
The following actions must be done for work of the cooking
hood in mode of an air recirculation:
- when installing do not connect the hood to the duct
(allowed not to install the adapter duct);
- Install additional charcoal filters into the cooking hood
(2 pcs.).
The charcoal filters are not included into the delivery set of
the cooking hood and should be purchased separately.
The charcoal filters are not subject to cleaning and should
be replaced with new after 3-4 months.
5
6
2
1
3 4
