EXTRACTOR FAN STRUCTURE
Technical features:
Construction of the cooking hood
1 – Decorative box with mounting bar
2 – Housing of kitchen hood with control panel
3 – Internal housing
4 – Motor
5 – Fat filters
Following is included into delivery set:
• Cooking hood
– 1 pc.
• Installation kit
– 1 pc.
• User manual
– 1 pc.
• Warranty certificate
– 1 pc.
• Box packaging
– 1 pc.
Model
R 60
R 90
Network voltage, V
220…240
220…240
Frequency, Hz
50
50
Rated current, А
0,86
0,86
Control
Slide switch
Number of motors, pcs.
1
1
Motor power, W
100
100
Overall power, W
180
180
Performance, cubic m./hour
700
700
Noise level, dB
58
58
Amount of fat filters (five-layer aluminum), pcs.
2
2
Amount of glow lamps (40W), pcs.
2
2
Air duct diameter, mm
120
120
Dimensions without air duct (WxDxH), mm
600х495х1050
900х540х1050
Weight, kg
14,6
19,5
Colour
White/ Black /Ivory
