PS Engineering
PMA4000 Series Audio Selector Panel and Intercom System
Installation Manual
200-041-0002 Page 1-3 Rev 5, March 2007
Unit Part Number
PMA4000 TSO 11942
PMA4000 w/IRS 11941
B. PMA4000 Installation Kit: 250-0041-0001
Part Number Description Quan
575-004-0005 Faceplate (Square) 1
475-632-0006 Mounting Screws6-32X3/8”Phil-Pan Black 2
625-002-0001 Knob, outer 1
625-002-0004
625-010-0002 Knob, inner
Knob insert pointer 1
1
425-025-0009 Connector Shell Male 1
425-025-0010 Connector Shell Female 1
425-020-5089 Crimp Pin, male 25
425-020-5090 Crimp Socket, female 25
701-015-1501 Dropping Resistor, 15 Ω, 15 Watt, (required in 28
VDC installation)
1
475-002-0002 Connector Thumbscrews 4
625-025-0001 Connector Hood 2
430-400-0028 Mounting Shim– 0.028 in 1
430-400-0050 Mounting Shim –0.050 in. 1
200-041-0002 Operator's and Installation Manual 1
1.6 Optional remote volume control (P/N 250-004-0020)
This kit contains:
1 ea. 10K
Ω Potentiometer P/N 675-020-0103
1 ea. knob, Black 1/4" Shaft w/Set Screw P/N 625-020-0005
1.7 Optional 2 ¼”mounting plate kit (250-004-0005)
This kit contains:
1 ea. 2 ¼” Mounting plate for instrument hole mounting, P/N 575-004-0001
1 ea. Mounting Shim, 430-400-0090
1.8 EQUIPMENT REQUIRED BUT NOT SUPPLIED
A. Speaker, 4 Ω
B. Headphones, 150 Ω mono, up to 4 as required
C. Microphones, up to 4 as required
D. Interconnect Wiring
E. Contact Crimping Tool, AMP 601966-1 (or MS22520 equiv.), with Positioning Tool
601966-5
F. Headphone Jacks (As Required)
G. Microphone Jacks (As Required)
H. Circuit Breaker: 1 ea. 3 amp.
1.9 LICENSE REQUIREMENTS
None
