2.9 Microphone gain reduction
For installations in very noisy aircraft, a reduction in the intercom microphone input gain may be desirable.
The PAR200A has two DIP switches located on the main board that can switch the inputs to a lower gain
setting. PS Engineering installers call for the Service Aid.
Figure 2-3 DIP switches
Change the settings as shown in the table below.
Switch Bank Switch Noisy Cockpit Normal Cockpit
Pilot Microphone
J5 1 OFF ON
2 ON OFF
Copilot Microphone
3 OFF ON
4 ON OFF
J4 Passenger 1 Microphone
1 OFF ON
2 ON OFF
Passenger 2 Microphone
3 OFF ON
4 ON OFF
Table 2-5 Microphone gain settings
1
2
3
4
5
6
ON OFF
ON OFF
