PS Engineering
PMA8000B-MP3 Audio Selector Panel and Intercom System
Installation and Operator’s Manual
200-890-0600 Page 1-4 Rev. 6, Oct. 2010
1.6 EQUIPMENT SUPPLIED
1 ea. of the following units:
Model Description Part Number
PMA8000B-MP3 PMA8000B-MP3 Audio Panel with Marker Beacon and Stereo
intercom, includes internal 1G MP3 Player 050-890-0602
PMA8000B- Installation Kit: 250-890-0000
Description Quantity Part
Number
PMA8000B-MP3 installation rack assembly 1 430-890-0040
PMA8000B-MP3 Rack back plate 1 430-890-0050
44-pin connector kit 2 120-891-2045-
Backshell, connector 2 625-025-2465
Backshell Retainer 2 431-881-0100
4 40 X 7/16 screw w/nylon patch 4 475-440-0007
4 40 X 3/8 screw w/lock washer 4 475-440-1038
4-40 Lock Nut 1 475-013-0001
Solder Lug 1 475-009-0001
Cable Clamp 1 625-001-0002
#6-32 x ½” Flat head Philips screw 6 475-632-0012
#6-32 Clip Nut 6 475-630-0002
Included with PMA8000B-MP3:
Cable, USB to 2.5 mm 4-conductor, PS Part Number
425-921-3983
USB-to-USB adapter PS Part number 425-003-1454
1.7 EQUIPMENT REQUIRED BUT NOT SUPPLIED
a. Circuit Breaker: 1 ea; 5 amp PULL TYPE REQUIRED for PMA8000B-MP3
b. Speaker, 4 
c. Headphone Jacks (Stereo, as Required)
d. Microphone Jacks (as Required)
e. Headphones, 150  (Stereo), up to 6 as required
f. Microphones, up to 6 as required
g. Marker Antenna (75 MHz, VSWR <1:1.5, and appropriate for the airspeed)
h. Interconnect Wiring
1.8 OPTIONAL ITEMS
a. Cell Phone Patch Cord, 2.5mm to 2.5mm, PS Part Number 425-006-7026
b. Music Patch Cord, 3.5mm to 5.5mm, PS Part Number 425-006-2535
1.9 LICENSE REQUIREMENTS
None
Note: The PMA8000B-MP3 only supports Wave (.wav), unprotected Windows Media Files (.wma)
and MP3 (.mp3) file types. It does not support iTunes format files.
