PS Engineering
PMA7000M-S Series Audio Selector Panel and Intercom System
Installation and Operator’s Manual
200-070-0012 Page 1-2 Rev. 12, Sept. 2000
A six-station voice activated (VOX) intercom is included in the PMA7000M-S. This system has PS Engi-
neering’s exclusive IntelliVox® circuitry that eliminates manual adjustments. The system contains six sepa-
rate VOX mic circuits, and only opens the microphone channel in use.
The intercom system incorporates pilot isolate and crew modes, two stereo music inputs with "Soft Mute,"
and LED indicators for swap and transmit indications. Intercom control is through front panel-mounted
knob and 3 position mode switch. A single volume controls intercom level for the pilot and copilot. Passen-
ger headphone volume is factory set, and adjusted in flight with headset-mounted volume controls. Passen-
ger volume control is further adjustable through screwdriver access in the top of the unit. Intercom squelch
is automatic.
An optional 3-light Marker Beacon receiver is integrated in the PMA7000M-S. This provides the necessary
Marker Beacon lights and audio indications necessary for an Instrument Landing System (ILS) approach.
1.4 APPROVAL BASIS -
TSO Approval.
The PMA7000M-S, and PMA7000S Audio Selector Panels are FAA approved under TSO C50c (Audio
Amplifiers) and TSO C35d (Marker Beacon Receivers). In addition, they are approved by the Joint Air-
worthiness Authorities under JTSO C50C and JAR-TSO 2C35d.
All systems comply with relevant portions of EUROCAE RTCA MPS WG No. 7/70, DO-143 and (Marker
Beacon Receivers), ED-14C/DO-160C (Environmental Conditions and Test Procedures for Airborne
Equipment), ED12B/DO-178B (Software Considerations for Airborne Equipment) and ED- 18/DO-214
(Audio Systems Characteristics and Minimum Operational Performance Standards for Aircraft Audio Sys-
tems).
NOTE: The optional message annunciators contained in Option 1 and Option 2 are not TSO-approved, and
the installer must determine the relevant approval basis prior to installation. Contact PS Engineering for
information regarding FAA approval.
Operation is subject to the following conditions:
This device may not cause harmful interference.
This device must accept any interference received, including interference that may cause undesired opera-
tion.
1.5 SPECIFICATIONS
TSO COMPLIANCE
Marker Beacon: C35d, Class A
Audio Selector/Intercom: C50c, Class A
APPLICABLE DOCUMENTS: RTCA/DO-214
RTCA/DO-143
RTCA/DO-160C
RTCA/DO-178B
ENVIRONMENTAL Qualifications: A1D1/CA(MN)XXXXXXBBBBTBKXX
Temperature Range:
Operating:
Storage:
-15º C to 55ºC
-40º C to 85ºC
Altitude: Up to 50,000 feet in an non-pressurized area of
the cockpit.
DIMENSIONS: Height: 1.3 in. (3.3 cm) Width: 6.25 in. (16.9 cm)
Depth: 6.8 in. (17.3 cm)
WEIGHT (With Rack & Connectors): 1.5 lb. (0.54 kg)
