Figure 10: sample system connection diagram 2 – PRG Ethernet Switch User Manual
Page 11
PRG SERIES 400
®
ETHERNET SWITCH USER MANUAL
9
Figure 10: Sample System Connection Diagram 2
* Fiber optic connections available only with the 10-Port Ethernet Switch model.
A
B
A
B
CAT5e CABLE TO
LOCAL RACKS
SERIES 400 RACK
FROM REMOTE RACKS
FIBER OPTIC CABLE
TO REMOTE RACKS
FIBER OPTIC CABLE
B
A
A
B
A
B
PRG S-400 10-PORT
ETHERNET SWITCH
